- Universal probes for common but constraining applications.
- 8mm diameter probe housing. Can be clamped over its entire length.
- Measuring bolt mounted on a ball bearing.
- Both the probe housing and the ball-bearing guide are separate from one another, so that the measuring bolt moves easily even if the probe is not clamped appropriately.
- Degree of protection IP65 according to IEC 60529.
- Fixing shank: Ø 8 mm
- Insert thread: M2.5
- Insert with ball tip: Ø 3 mm
- Cable: 2 m
- Wide range of accessories including measuring inserts, spring sets, etc.
- LVBDT probes compatible with measuring equipment from other makers available on request.
- Excellent repeatability, durability and longevity.
TESA - GT22 Probe - w/ Radial Cable - Range +/- 1mm/.040"
| Item No. | Measuring Force | Range | Housing Dia. | Our Price | QTY |
|---|---|---|---|---|---|
| 32.10921 | .16N | +- 1mm | 8mm | $574.00 | |
| 32.10922 | .25N | +- 1mm | 8mm | $574.00 | |
| 32.10923 | .40N | +- 1mm | 8mm | $574.00 | |
| 32.10924 | .63N | +- 1mm | 8mm | $418.00 | |
| 32.10925 | 1.00N | +- 1mm | 8mm | $574.00 | |
| 32.10926 | 1.60N | +- 1mm | 8mm | $574.00 | |
| 32.10927 | 2.50N | +- 1mm | 8mm | $574.00 | |
| 32.10928 | 4.00N | +- 1mm | 8mm | $574.00 |
