Mark-10 - Manual Test Stand - TSB100 - Lever Operated - 100 lbF (500 N)

Starting at $945.00

Tension and Compressive Testing to 100 lbF (500 N)

The lever operated Force Measurement Test Stand Model TSB100 is an economical solution for quick-action tensile testing and compression testing of up to 100 lbF (500 N) of force.
Constructed of rugged components, this test stand is durable enough for the factory floor, yet precise enough for laboratory environments.
Force Gage sold separately

Additional Information +

Item No.	Our Price	QTY
TSB100	$945.00

Features:

Maximum force: 100 lb [500 N]
Maximum travel, with stops (optional): 3.75" [95 mm]
Maximum travel, without stops: 6" [152 mm]
Travel rate: 3" [76.2 mm]/lever revolution
Compatible with all Mark-10 force gauges, accessories and grips
Loading lever can be positioned in 30° increments for ease of operation
Mounting holes for bench mounting
Optional adjustable travel stops
Precision ground rack for smooth precision motion
Removable base plate with 25 #10-32 UNF holes for fixture mounting
Low force friction brake
